19 Cables and Connectors
170 5700/5800 GPS Receiver User Guide
5800 Operation
19.1
Introduction
This chapter provides pinout information for the 5800 receiver
standard and optional cables. This information can be used to prepare
special cables for connecting the 5800 receiver to devices and
instruments not supported by the standard and optional cables.
19.2
Port 1 and 2 Connectors
Figure 19.1 shows the location of the 5800 receiver serial ports.
Figure 19.1 5800 serial ports
1
2
BARCODE S/N LABEL
Port 1
Port 2
