5700/5800 GPS Receiver User Guide 151
Software Utilities 16
5800 Operation
160.1 Configuring the 5800 receiver
To configure a 5800 receiver using GPS Configurator:
1. Connect Port 1 or 2 on the receiver to a serial (COM) port on
the computer and apply power.
2. To start GPS Configurator, click , then select
Programs / Trimble / GPS Configurator / GPS Configurator.
3. Select 5800 in the Device Type dialog.
The software automatically establishes a connection with the
5800 receiver.
4. Make appropriate selections for your required receiver settings.
For more information, refer to the GPS Configurator Help.
5. Click
Apply.
The settings in GPS Configurator are applied to the receiver.

Trimble 5700 Specifications

General

Frequency	L1/L2
Power Consumption	6.0 W
Receiver Type	L1/L2 GPS receiver
Data Logging	Internal memory
Communication	Bluetooth
Operating Temperature	-40°C to +65°C
Power Supply	External
RTK Accuracy	10 mm + 1 ppm (horizontal), 15 mm + 1 ppm (vertical)
