5700/5800 GPS Receiver User Guide 203
Troubleshooting C
5700 and 5800
Reference receiver is
not broadcasting.
Port settings between
reference receiver and radio
are incorrect.
Using Trimble Survey Controller,
connect to the reference radio
through the receiver. If no connection
is made, connect directly to the radio
and change the port settings. Try to
connect through the receiver again to
ensure that they are communicating.
Faulty cable between receiver
and radio.
Try a different cable.
Examine the ports for missing pins.
Use a multimeter to check pinouts.
No power to radio. If the radio has its own power supply,
check the charge and connections.
If power is routed through the
receiver, ensure that the receiver’s
external power source is charged and
that power output on Port 3 is
enabled.
Table C.2 Receiver issues (continued)
Issue Possible cause Solution
