4 General Operation
56 5700/5800 GPS Receiver User Guide
5700 Operation
Figure 4.2 Charging the batteries
The two internal batteries take approximately eight hours to charge.
They are charged individually, so each battery takes approximately 4
hours to charge.The internal batteries start charging whenever an
external power supply of greater than 15 V is detected.
Each 5700 receiver in your system is supplied with two internal
lithium-ion battery packs. To charge both sets of batteries, connect
both receivers to power supplies as shown in Figure 3.2.
2
3
t
Power/serial data cable
To AC
power supply
