109
Maintenance and Adjustment
Front Suspension Setting Chart
The standard suspension settings provide a
comfortable ride and good handling
characteristics for general, solo riding. The
charts above show suggested settings for the
front suspension.
Rear Suspension
Rear Suspension Setting Chart
The standard suspension settings provide a
comfortable ride and good handling
characteristics for general, solo riding. The
charts above show suggested settings for the
rear suspension.
An increase in spring pre-load requires firmer
damping, a reduction in spring pre-load
requires softer damping.
The damping must be adjusted to the road
conditions and the spring pre-load.
Loading Spring
Pre-Load¹
Solo Riding - Standard 8
Solo Riding - Comfort 8
Rider and Luggage 8
Rider and Passenger 8
Rider, Passenger and
Luggage
8
¹ Number of turns counter-clockwise from
the fully clockwise position.
Loading Spring
Pre-Load²
Rebound
damping²
Solo Riding -
Standard
20 12
Solo Riding -
Comfort
20 18
Rider and luggage 10 12
Rider and
Passenger
012
Rider, Passenger
and Luggage
010
² Number of clicks counter-clockwise from
the fully clockwise position noting that the
first stop (click) is counted as 1.
