Triumph Tiger Explorer User Manual

39
General Information
1. Oil pressure/low oil level warning
light
2. Display area, oil pressure shown
High Coolant Temperature Warning
Light
With the engine running, if the
engine coolant temperature
becomes dangerously high, the
high coolant temperature warning light in the
tachometer will illuminate.
Caution
Stop the engine immediately if the low oil
pressure warning light illuminates. Do not
restart the engine until the fault has been
rectified.
Severe engine damage will result from
running the engine when the low oil
pressure warning light is illuminated.
MIN
-1
x 1000
2
1
Caution
Stop the engine immediately if the high
coolant temperature warning light
illuminates. Do not restart the engine until
the fault has been rectified.
Severe engine damage will result from
running the engine when the high coolant
temperature warning light is illuminated.

Triumph Tiger Explorer Specifications

General

Displacement	1215 cc
Transmission	6-speed
Final Drive	Shaft
Tires Front	110/80 R19
Tires Rear	150/70 R17
Engine Type	Liquid-cooled, 12-valve, DOHC, inline 3-cylinder
Fuel System	fuel injection
Front Suspension	adjustable rebound and compression damping
Rear Suspension	adjustable rebound damping
Front Brakes	Dual 305mm floating discs, 4-piston calipers, ABS
Rear Brakes	Single 282mm disc, ABS
Frame	Tubular steel trellis frame
Fuel Capacity	20 L (5.2 US gal)
