66
General Information
Rotate the handlebar so that the etched +
marking on the handlebar aligns with the
front left hand split line of the clamp riser.
1. Upper clamp, left hand
2. Clamp split line, front
3. Handlebar + mark
Tighten the 10 mm bolts to 26 lb ft
(35 Nm).
Re-install the 8 mm bolts to the front
positions and tighten to 15 l b f t ( 2 0 N m ).
Windshield
Note:
• The windshield fitted to this
motorcycle can be adjusted
without the use of tools.
To Adjust the Windshield
1. Adjuster knob, right hand side shown
2. Adjustment block
3. Adjustment plate
Never attempt to clean or adjust the
windshield while riding the motorcycle.
Removal of the rider's hands from the
handlebars while riding the motorcycle will
diminish the ability of the rider to maintain
the control of the motorcycle. Attempting
to clean or adjust the windshield while
riding the motorcycle may result in loss of
motorcycle control and an accident.
