64
General Information
Triumph Accessory D-lock
Storage
Space is provided under the rear seat to store
a Triumph accessory D-lock (available from
your Triumph dealer).
Secure the lock as follows:
Remove the rear seat (see page 61 ).
Release the strap and remove the handbook
and tool kit.
Position the U-section of the lock to the rear
fender tray support features, ensuring the
open end faces towards the front of the
motorcycle.
Position the lock body into the rear fender
tray as shown below.
1. Lock U-section
2. Lock body
Fit the tool kit and handbook above the
D-lock and secure using the tool kit strap.
Re-install the rear seat (see page 61 ).
Electrical Accessory Socket
1. Electrical accessory socket
An electrical accessory socket is provided on
the motorcycle, located in front of the fuel
tank.
The socket will provide a 12 Volt electrical
supply. It is protected by a 10 Amp fuse,
therefore items with a current draw greater
than 10 Amps must not be plugged into the
socket.
A plug, suitable for use with the accessory
socket, is available from your authorized
Triumph dealer.
