General Information
Warning Lights
Note:
• When the ignition is switched on,
the instrument warning lights will
illuminate for 2 seconds and will
then go off (except those which
remain on until the engine starts,
as described in the following
pages).
Turn Signals
When the turn signal switch is
pushed to the left or right, the
turn signal indicator light will flash on and off
at the same speed as the turn signals.
High Beam
When the ignition is switched on
and the headlight dimmer switch
is set to 'high beam', the high
beam warning light will illuminate.
Low Fuel
The low fuel indicator will
illuminate when there are
approximately 1.19 US gallons
(4.5 liters) of fuel remaining in the
tank.
Neutral
The neutral warning light
indicates when the transmission is
in neutral (no gear selected). The
warning light will illuminate when the
transmission is in neutral with the ignition
switch in the ON position.
Low Oil Pressure/Low Oil Level
Warning Light
When the ignition is switched on,
the low oil pressure/low oil level
warning light will illuminate for 2 seconds
and will then go off if the oil level is correct.
If the oil level is low, the low oil pressure/low
oil level warning light in the tachometer will
illuminate and 'oil Lo' will be visible in the
display screen. Do not start the engine until
the engine oil level has been rectified (see
page 94).
With the engine running, if the engine oil
pressure becomes dangerously low, the low
oil pressure/low oil level warning light in the
tachometer will illuminate and 'oil Pr' will also
be visible in the display screen.
Caution
Running the engine with insufficient oil will
cause engine damage. If 'oil Lo' is visible in
the display screen do not start the engine.
Investigate the cause before attempting to
start the engine.
