General Information
Speedometer and Odometer
The digital speedometer indicates the road
speed of the motorcycle. The read-out
displays the motorcycle road speed in
increments of one mile (or kilometer) per
hour.
The electronic odometer and two trip meters
are in the display screen. For details of the
operation of the odometer and trip meters,
please refer to the following pages.
Tachometer
The tachometer shows the engine speed in
revolutions per minute - rpm (r/min). At the
end of the tachometer range there is the
'red zone'. Engine rpm (r/min) in the red
zone is above maximum recommended
engine speed and is also above the range for
best performance.
Trip Computer
1. Scroll button, up
2. Scroll button, down
3. Set button
To access the trip computer information,
press and release the set button on the left
hand switch cube until the desired display is
visible. The display will scroll through in the
following order:
• Trip Meter 1;
• Trip Meter 2;
• Air temperature;
• Tire Pressure Monitoring system -
if equipped;
•Set up.
Note:
• The tire pressure monitoring
system (TPMS) is an accessory
which must be installed by your
authorized Triumph dealer. The
TPMS display will then be
activated by your authorized
Triumph dealer.
Caution
Never allow engine rpm to enter the
'red zone' as severe engine damage may
result.
1
2
3
