General Information
TPMS Sensor ID Number
An ID number for each tire pressure sensor is
printed on a label which is on the sensor. This
number may be required by the dealer for
service or diagnostics.
If the TPMS has been installed at the factory,
labels identifying the front and rear TPMS
sensor ID numbers will be affixed to the
spaces below.
If the TPMS is being fitted to the motorcycle
as an accessory, ensure that the dealer
records the front and rear TPMS sensor ID
numbers in the spaces provided below.
System Display
1. TPMS symbol
2. Tire pressure display
3. Front tire, identified
4. Rear tire, identified
To access the tire pressure display, turn the
ignition to the ON position.
Press and release the set button on the left
hand switch cube until 'PSI' or 'bAr' is visible
in the display screen.
Press and release the scroll button to select
the front or rear tire pressure.
When the tire pressure monitoring system
has been selected, — — 'PSI' or 'bAr' will be
visible in the display screen until the
motorcycle is travelling at a speed greater
than 12 mph (20 km) and the tire pressure
signal is received.
To exit the tire pressure display, press and
release the home button and the odometer in
trip 1 menu will be displayed.
Front Sensor
Rear Sensor
cgjp_6_1
4
3
2
1

Triumph Tiger Explorer Specifications

General

Displacement	1215 cc
Transmission	6-speed
Final Drive	Shaft
Tires Front	110/80 R19
Tires Rear	150/70 R17
Engine Type	Liquid-cooled, 12-valve, DOHC, inline 3-cylinder
Fuel System	fuel injection
Front Suspension	adjustable rebound and compression damping
Rear Suspension	adjustable rebound damping
Front Brakes	Dual 305mm floating discs, 4-piston calipers, ABS
Rear Brakes	Single 282mm disc, ABS
Frame	Tubular steel trellis frame
Fuel Capacity	20 L (5.2 US gal)
