22
General Information
Instrument Panel Layout
1. C l o c k
2. Service interval indicator
3. Speedometer
4. Fuel gauge
5. Engine management malfunction
indicator light
6. Left hand turn signal light
7. ABS warning light
8. Tachometer 'red zone'
9. Tire pressure warning light (if Tire
Pressure Monitoring System (TPMS)
is fitted)
10.Right hand turn signal light
11. Neutral indicator light
12.High beam indicator light
13.Low fuel level indicator light
14.Alarm/immobilizer status indicator
light (alarm is an accessory fit)
15.Traction control light (if traction
control is fitted)
16.Cruise control light
17. Tachometer
18.High coolant temperature warning
light
19.Low oil pressure/low oil level
warning light
20.Tire pressure display (if Tire Pressure
Monitoring System (TPMS) is fitted)
21. Fr o s t s y m b ol
22.Heated seat symbol (if heated seats
are fitted)
23.Selected gear
24.Coolant temperature gauge
25.Hazard warning lights button
26.Home button
