Parts Identification
PARTS IDENTIFICATION
18.Brake/tail light
19.Rear brake fluid reservoir
20.Oil filler cap
21. Mirror
22.Front fork adjuster
23.Windshield adjuster, right hand side
24.Headlight adjuster
25.Screen
26.Front fork
27.Engine oil level sight glass
28.Clutch line
29.Rear brake pedal
30.Rear suspension spring pre-load
adjuster
31. M uf fl er
18
19 20
21 24
25
26
28 27293031
23
22
