3–14
DEPTH INDICATOR (SPECIAL KEY)
The Depth Indicator feature allows the operator to set the depth
mode and to calibrate the depth indicator. The depth mode tells the
gauge how it will receive data about the source rod depth. The
Model 3450 offers two depth modes: automatic and manual. In the
automatic mode, the gauge software reads a depth strip on the index
rod to determine the source rod depth. In the manual mode, the
operator enters the source rod depth at a gauge prompt whenever
taking a measurement.
To access the Depth Indicator menu, press 〈3〉 at the Gauge Setup
menu shown on page 3–9.
To select a depth mode, press either 〈1〉 Automatic or 〈2〉 Manual.
To calibrate the depth strip, press 〈3〉 Calibrate Depth.
After the depth mode is selected, the gauge sets the mode and
returns to the Gauge Setup menu. To return to the Ready screen,
press the
〈ESC〉 key.
To calibrate the depth strip, press 〈3〉 and follow instructions on the
gauge screen.
-Depth Indicator-
1- Automatic
2- Manual
3- Calibrate Depth
