VIEW DATA
The Model 3450 offers two methods of viewing data. The operator
can view either the last measurement results, or any project data,
including project notes.
To view the last measurement results, press the 〈RECALL〉 key.
Use the arrow keys to scroll through the displays. Return to the
Ready screen by pressing the
〈ESC〉 key.
To view any project data, press the 〈PROJECT〉 key. As shown on
page
5–5, the gauge displays the current project on the first line of
the Project menu. Use the arrow keys to scroll through the project
names. When the gauge displays the desired project number, press
〈3〉. The gauge displays:
The gauge displays the station number on the third line. To scroll
through the station numbers, press
〈↑〉. To scroll through the project
data for the displayed station number, press
〈↓〉. Return to the Ready
screen by pressing the
〈ESC〉 key.
PRINT/UPLOAD DATA
The Print option within the Project menu allows the operator to
print (or upload) project data stored in the gauge. To print stat test
or drift test data, see Appendix C.
Appendix H provides instructions on using the HyperTerminal
program in current versions of Microsoft→ Windows→ to print
(upload) data to a computer.
For details on setting up the gauge software for printing, see the
Printer (Special Key) section on page 3–13.
#: Your Project
ID: xxxxx
Station: x
