To connect the gauge to a printer or computer, remove the cover
from the 9-pin serial port on the back of the gauge. Connect a serial
printer cable to the gauge serial port. Connect the serial printer cable
to the printer (or computer) serial port.
At the Project menu shown on page 5–5,
press 〈4〉. The gauge
displays the Print Project menu:
From this menu, the gauge can print (or upload) either a single
project or all projects.
To print (or upload) a single project, use the arrow keys to scroll
through the project names displayed on the first line. When the
gauge displays the desired project, press
〈1〉. The gauge prints (or
uploads) the project and returns to the Print Project menu shown
above. Press the
〈ESC〉 key to return to the Ready screen.
To print (or upload) all projects, press 〈2〉 at the Print Project menu
shown above. The gauge prints (or uploads) all the projects and
returns to the Print Project menu. Press the
〈ESC〉 key to return to
the Ready screen.
1-
Print This Project
2-
Print All Projects
