TSI Instruments Certifier Plus User Manual

Introduction and Parts Identification 1-3
Certifier Plus High Flow Test System, Full Kit (Model 4080-F)
Item
Number
Description
Replacement
Part Number
Qty.
1
Interface Module
a
4089
1
2
High Flow Module
b
4081
1
3
Inlet Filter, HEPA, 22 mm x 22 mm M/F (for use with 4081)
1602341
1
4
Adapter, high pressure port
1611221
1
5
Adapter, 22 mm x 6 mm (to connect 4081 to Low Flow Filter)
1102091
2
6
Adapter, 15 mm ID x 22 mm OD
1102093
1
7
Airway pressure fitting with screen
1611330
1
8
Pressure tubing, silicone, 1/8-inch ID x 1/4-inch OD x 48 in.
3002053
1
9
Velcro
®
strap for use on High Flow Module
2913110
1
10
Flow module cable, REDEL
®
straight plug to 4 pin mini-DIN
130384
1
12
Power supply 100/240 VAC to +12 VDC 2.1 mm plug,
includes plug set with NA, UK, EU, CN, SAA connectors
130400
1
13
Battery, 4 cell Lithium-Ion 7.2 V 6.4 AHr (pre-installed)
130385
1
14

130392
1
20
Certifier Oxygen Sensor Kit
4073
1
24
RAM Mounting Kit for Interface + Flow Module
130399
1
29
Adapter, 22 mm F to 22 mm F, straight
130373
1
30
Adapter, 15 mm M to 22 mm F, pediatric cuff
130374
1
31
Deluxe carrying case, fitted (19 x 14.75 x 6.5 inches)
130393
1
32
Test Lung, adult, 1.0L
130396
1
33
Stylus, capacitive touch
130370
1
a
If ordering a 4089-F Interface Module Kit for replacement, items 1, 10, 12-14, 20, 24, and 29-33 are included.
b
If ordering a 4081 High Flow Module Kit for replacement, items 2 through 9 are included.
