CHAPTER 2
Flow Analyzer Overview
I n s t r u m e n t O v e r vi e w
4089 Interface Module, Back
4089 Interface Module, Front
1.
Flow Module Connector (A)
7.
Screw hole for USB-C cable lock
2.
Flow Module Connector (B)
8.
Tilt Stand
3.
DC Power Input (2.1 mm barrel jack)
9.
Cable Retainer
4.
Power Button (On/Off)
10.
Mounting holes (2), threaded M4
5.
USB-A Connectors (2)
11.
Touchscreen Display
6.
USB-C Communications Output
12.
Protective Cover
