3.11 Stickers Description
Symbol
Meaning
Part Number
Location
Caution! Hot
steam.
LAB048-0058
Near the safety
valve
Protective earth
(Ground)
LAB048-0020
Near the earthing
screw
Caution! Hot
surface.
LAB048-0023
On the rear cover
above the water
strainer
Press & Hold
Until “System
Ready” is
Displayed = 10
sec.
LAB048-0461
(Automatic
door only)
On the door right
edge
Don’t Touch
Microswitches
please Contact
Tuttnauer
Service
LAB048-0462
On the door frame
behind the door
cover
Don’t Touch
Microswitches
please Contact
Tuttnauer
Service
LAB048-0463
On the door frame
behind the door
cover
ON
OFF
On-Off
LAB048-0018
Near the Power
switch
