Tuttnauer 3840 ELVG-D - Periodical Tests; Safety Valve Replacement (PED Type)

Page 83
5. In order not to damage the autoclave cover, use a 20 mm wrench
to apply a counter force on the base (2) of the safety valve.
6. Replace it with a new safety valve (use an original only).
7. Reassemble the safety valve shield.
8. Test autoclave cycles.
No.
Description
Cat. No.
No.
Description
Cat. No.
1
Generator
safety
valve
PED
3.5 Bar
SVL029-
0088
4
Washer
CMT240-0022
ASME
40 psi
SVL029-
0090
5
Nut
CMT240-0020
2
Chamber
safety
valve
PED
2.8 Bar
SVL029-
0028
6
Safety valve
base
CMV100-
0004
ASME
40 psi
SVL029-
0090
7
Screw
BOL190-0150
3
Autoclave rear wall
N/A
8
Safety Valve
Shield
COV411-0010
1 or 2
1 or 2
4
7
8
3
4
5
6
6
2
1
