Tuttnauer 3840 - Page 15

Page 13 of 110 Pages
Length
92.0 cm
(36.2")
76.5 cm (30")
(For 3840 PV,
92.0 cm
(36.2")
Maximum dimensions (door
open)
Length
141 cm (55.5")
126 cm (49.6")
Width
80.0 cm
(31.5")
80.0 cm
(31.5")
Distance between supporting
legs
Rear to
front
72.0 cm
(28.3")
54.0 cm
(21.2")
Front legs
48.0 cm
(18.9")
48.0 cm
(18.9")
Rear legs
62.0 cm
(24.4")
62.0 cm
(24.4")
Value: 3870
Value: 3850/3840
Weight
78 kgs (172 lbs.)
58 kgs (128 lbs.)
Weight per support area
(max. load)
126 kgs (278 lbs.)
106 kgs (234 lbs.)
Shipping weight
102 kgs (225 lbs.)
82 kgs (181 lbs.)
Shipping
dimensions
Width
80 cm (31.5")
80 cm (31.5")
Height
80 cm (31.5")
80 cm (31.5")
Length
120 cm (47.2")
120 cm (47.2")
Volume
77 cm
3
(4.7"
3
)
77 cm
3
(4.7"
3
)
Mineral-free
water reservoir
Max.
water
volume
6.0 lit. (1.58 gal.)
6.0 lit. (1.58 gal.)
Min.
water
volume
2.0 lit. (0.53 gal.)
2.0 lit. (0.53 gal.)
Maximum load per tray
Unwrapped
6 kgs (11 lbs.)
Unwrapped
6 kgs (11 lbs.)
Maximum solid load
Unwrapped
30 kgs (66 lbs.)
Unwrapped
10 kgs (22 lbs.)
Tray dimensions
19.5 x 69.0 cm
( 7.7" x 27.2" )
19.5 x 51.0 cm
(7.7" x 20.1 ")
Max. Allowable Working
pressure (MAWP)
2.8 bar (40 psi)
2.8 bar (40 psi)
No. of trays
2
2
IMS cassettes (optional)
15
15
