LOCATION OF PARTS - HANDLE BAR
15. Pass by switch
7. Throttle grip
13. Clutch lever
9. Fuel tank cap
8. Electric starter switch
10. Horn switch
11. Turn signal lamp switch
12. High / low beam switch
14. Rear view mirror L
3. Master cylinder (front)
5. Rear view mirror R
1. Connected instrument cluster
2. Ignition cum steering lock
4. Engine cut off switch
6. Front brake lever
11
KNOW YOUR TVS APACHE RTR 200 4V
2
1 3 54
8
11
161514
7
9
10
12
13
6
