ENGINE CUM TRANSMISSION OIL
Check the engine cum transmission oil level
periodically. The gauge oil level is provided at the
right-hand side crankcase cover.
8. If the oil level is below the minimum level, top up
with TVS TRU4 FULLY SYNTHETIC oil (SAE 10W 30
API-SL, JASO MA2) upto the maximum level mark.
Do not overfill.
7. The oil level should be between the minimum and
maximum level marks on the gauge as shown in
the figure.
9. Wipe out the oil traces with a clean cloth to
prevent dust accumulation and re-fix the gauge.
Make sure that no foreign object gets in the crankcase
while topping up the engine oil.
Do not run the vehicle with insufficient / without
engine cum transmission oil as it will cause serious
damage to the engine components.
Excessive oil filling will cause oil leak and other
malfunctions. Always use TVS TRU4 FULLY
SYNTHETIC oil only (SAE 10W 30 API-SL, JASO MA2).
Correctly recycle or dispose the used engine oil in
order to avoid environmental pollution.
1. The check must be performed when engine is in
cold condition, after placing the motorcycle in
center stand with front wheel touching the
ground.
3. Wipe-off the surroundings of gauge oil level.
4. Remove the gauge oil level and wipe it clean.
5. Re-insert the gauge oil level by completely
screwing it in.
6. Once again remove the gauge and check the oil
level.
2. Placing the motorcycle in an upright position on a
horizontal and firm surface.
MAINTENANCE
Warning
Caution
Maximum
Minimum
68

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the TVS Apache RTR 200 4V 2021 and is the answer not in the manual?

TVS Apache RTR 200 4V 2021 Specifications

General IconGeneral
Displacement197.75 cc
Transmission5-speed
Fuel SystemFuel Injection
Front SuspensionTelescopic Forks
Rear SuspensionMono Shock
Wheelbase1353 mm
Seat Height800 mm
Kerb Weight152 kg
Fuel Tank Capacity12 Liters
Bore x Stroke66 mm x 57.8 mm
StartingElectric Start
Front Tyre90/90 - 17
Rear Tyre130/70 - 17
Ground Clearance180 mm
HeadlampLED
Tail LampLED
SpeedometerDigital
OdometerDigital
TachometerDigital
TripmeterDigital
Engine Type4 stroke, Oil cooled
Front BrakeDisc
Rear BrakeDisc
IgnitionDigital
ClutchWet, Multi-Plate
Frame TypeDouble cradle
ABSSingle-channel
