Steering angle : 35° (both sides)
Rear suspension : G a s c h a r ge d M o no s h oc k
absorber, 7 step adjustable with
rectangular swing arm
Seat height : 800 mm
Overall width : 790 mm
Ground clearance : 180 mm
Overall height : 1105 mm
Pay load : 130 kg
Maximum laden weight : 278 kg (incase of without ABS)
: 282 kg (incase of single channel ABS)
Frame : Double Cradle Split Synchro
STIFF (DCSSS)
Caster angle : 25.8°
Wheel base : 1353 mm
and 90% of fuel) : 152 kg (incase of single channel ABS)
Overall length : 2050 mm
Kerb weight (with toolkit : 148 kg (incase of without ABS)
Trail length : 95.5 mm
Front suspension : Telescopic oil damped
CHASSIS
Tyre pressure
Front : 1.75 kg/cm² (25 PSI)
Rear - solo : 2.00 kg/cm² (28 PSI)
Rear - dual : 2.25 kg/cm² (32 PSI)
Rear : 130/70 x 17 Tubeless
Tyre size
TYRE
Front : 90/90 x 17 Tubeless
BRAKES
Spark plug : BOSCH - UR4KE
Position lamp : LED lamp (12V, 3W x 2)
Head lamp : 12V, LED Headlamp
Ignition system : IDI - Engine load based digital ignition
ELECTRICAL
Generator : Fly wheel magneto 12V, 200W
Rear : Foot operated, 240 mm petal disc
Front : Hand operated, 270 mm petal disc
Battery type : 12V, 6 Ah
Type : AC generator
TECHNICAL SPECIFICATION
85
