TVS Apache RTR 200 4V 2021 User Manual

LOCATION OF PARTS - VEHICLE RIGHT SIDE
1. Disc plate front
4. Wheel speed sensor front
6. Caliper assembly front
8. Gauge oil level
9. Rear brake pedal
10. Rider foot rest R
13. Disc plate rear
11. Pillion foot rest R
5. Toner ring front
14. Rear wheel axle nut
15. Caliper assembly rear
12. Muffler assembly
16. Cover frame R
2. Cover toner ring
3. Front wheel axle nut
7. Location of spark plug
17. Location of ram air duct
13
KNOW YOUR TVS APACHE RTR 200 4V
1
16 17
2
11
1213 7
10
9 8
3
4561415
