LOCATION OF PARTS - VEHICLE FRONT AND REAR
6. Pillion handle
FRONT
1. Turn signal lamp front L
6. Turn signal lamp front R
5. Position lamps
4. Crash guard
REAR
3. Number plate lamp
3. Oil cooler
2. Reflex reflector
2. Head lamp assembly
4. Turn signal lamp rear L
1. Turn signal lamp rear R
5. Tail lamp assembly
