Engine cum transmission : TVS TRU4 FULLY SYNTHETIC oil
Engine cum transmission : 1200 ml (during servicing)
Turn signal lamp : 12V,10W x 4
Instrument panel : LCD / LED indicators
Tail / brake lamp : LED lamps (1W max. / 2.5W max.)
Number plate lamp : 12V, 5W x 1
CAPACITIES
Horn : 12V, DC x 2
Fuse : 12V, 15A x 2, 12V, 10A x 1
ELECTRICAL
Reserve : 2.5 litres
Fuel tank capacity : 12 litres (including reserve)**
oil grade (SAE 10W30 API-SL, JASO MA2)
oil and capacity 1400ml (during engine overhaul)
Front fork oil grade : KYB G10 oil
Front fork oil capacity : 325 ± 2 cc / leg
Brake fluid : TVS Girling DOT 3 / DOT 4
** The fuel tank is not a measuring instrument and the
capacity of fuel tank may slightly vary from the
indicated capacity.
Using the bulb other than the specified rating can
result in overloading of the electrical system or
premature failure of the bulb.
Specifications are subject to change without notice.
Caution
Note
TECHNICAL SPECIFICATION
86
