P.B. No1, Bythahalli, Kadakola post, Mysore - 571 311, India.
MANUFACTURER : TVS MOTOR COMPANY LIMITED
* Under warm condition
Piston displacement : 197.75 cc
ENGINE
Type : 4 stroke, Oil cooled, single
cylinder OHC
Cylinder bore : 66 mm
Stroke : 57.8 mm
Compression ratio : 9.7 : 1
Carburettor : Keihin CV 30 VE
Air filter : Viscous Paper filter
Oil filter : Wire mesh and micronic
paper filter
Lubrication system : Forced wet sump
Maximum power in kW : 15.09 (20.5 PS) @ 8500 rpm
Maximum torque in Nm : 18.1 Nm @ 7000 rpm
Engine idling rpm* : 1500 ± 100 rpm
Starting system : Electric starter
Maximum speed : 128 km / h
TRANSMISSION
Clutch : Wet - multiplate type
Gear shift pattern : 1 down and 4 up
Primary transmission : Helical gears
Secondary transmission : Chain and sprockets
II gear : 1.857
Primary reduction : 2.818
GEAR RATIOS
V gear : 0.880
III gear : 1.333
IV gear : 1.050
I gear : 2.917
Final reduction : 3.461
TECHNICAL SPECIFICATION
84
