CONTROL KEY
Your TVS Apache RTR 200 4V comes with a pair of
identical control keys. These keys are to operate
ignition cum steering lock, fuel tank cap and seat lock.
IGNITION CUM STEERING LOCK
1. 'OFF' position
The ignition switch enables and disables the electrical
circuit and steering lock. The three positions of the
switch are described below.
All electrical circuits are deactivated. The key can be
removed from the lock.
3. 'LOCK' position
2. 'ON' position
All electrical circuits are activated. The instrument
cluster and warning lights perform the self-diagnostic
cycle once upon activation. The engine can be started.
The key cannot be taken out from the lock.
Insert the key into the lock and turn it to 'OFF' or 'ON'
position to unlock the steering.
Turn the handlebar to the ‘left’ or ‘right’. Press the key
in and rotate it to the ‘LOCK’ position from ‘OFF’
position. All electrical circuits are deactivated and the
steering is locked. The key can be removed from the
lock.
Your TVS Apache RTR 200 4V steering can be locked
in both 'left' and 'right' directions.
Speedometer background illumination and position
lamps glow automatically once the ignition key is
turned ‘ON’ without activating other switches. Also,
the speedometer performs self diagnostic cycle. Wait
till the message ‘RACE ON’ appears on the speedo
dial.
15
KNOW YOUR TVS APACHE RTR 200 4V
Note
