Flashes when the ‘right’ side turn signal indication
is activated.
Blinks when the fuel level reaches to minimum safe
fuel level. It glows continuously when the fuel comes
below minimum safe level.
NA - Not applicable for present model
-NA-
2. Turn signal indicator right ( )
3. Immobilizer indicator ( )
4. Low fuel indication ( )
Glows when the vehicle is in neutral and goes ‘OFF’ if
the gear is shifted from neutral.
7. ABS warning lamp ( )
6. High beam indicator lamp ( )
Glows when the head lamp is activated in high beam.
5. Neutral indicator lamp ( )
ABS warning lamp blinks when the ignition key is
turned ‘ON’ and speedometer is performing self
check. This lamp goes ‘OFF’ once the vehicle reaches
the speed 6 km/h and above. If this lamp glows
continuously then have your vehicle checked at TVS
Motor Company Authorised Distributor or Dealer /
Authorised Service Center (refer page no. 04 for more
details).
KNOW YOUR TVS APACHE RTR 200 4V
17
If you leave the ignition key in ‘ON’ position and
vehicle is kept without moving for more than
3 minutes, an error message ‘CHECK SPEED
SENSOR’ will scrolls which is normal.
If you notice an error message ‘CHECK SPEED
SENSOR’ while the vehicle is in move, Contact
nearest TVS Motor Company Authorised Distributor
or Dealer / Authorised Service Center for rectification.
Note
This ABS warning lamp will blink whenever the
vehicle speed is less than 6 km/h which is normal. It
also indicates that the ABS is working fine.
Note
