14. Lean angle indicator
When this mode is selected (refer page no. 29), the
tachometer indication will indicate the leaning angle
information of the vehicle and the same data will be
displayed at the bottom of the cluster as shown.
23
KNOW YOUR TVS APACHE RTR 200 4V
Shift RPM indicator alerts the user to shift the gears
when engine reaches the specified RPM. Users can
set the RPM indication levels as per their riding
convenient in multiples of 1000 up to 12000 RPM
(refer page no. 29). When the engine reaches the set
RPM, red indicator in the digital speedometer glows
and indicates the user to shift to next higher gear.
12. Shift RPM indicator
Lean angle is calculated from the mobile device when
it is connected to the instrument cluster and lean
angle mode is set. The accuracy of the lean angle
information depend on the mobile device used,
orientation and placement of the mobile device on
the vehicle. Refer page No. 31 for detail procedure
connecting the mobile with the instrument cluster.
For best accuracy, it is recommended that the user to
mount the phone to a rigid part of the bike in vertical
position. Lean angle will not be displayed in
stationary condition.
Note
Note
Shift RPM indicator does not work when the vehicle is
in neutral or when the fifth gear is engaged.
By default the shift rpm is set to 7000 RPM. You can
set it to your convenience as per your riding habit.
13. Tachometer
Tachometer indicates the engine speed in multiples
of 1000 RPM (Revolutions Per Minute).
