Press the lever towards grip to disengage the drive. It
is used to disengage the clutch while shifting the
gears.
4. Clutch lever
5. Pass-by switch
If the head lamp is already glowing in ‘High’ beam, the
pass-by system will not work.
The head lamp glows automatically once the engine
is started. If the head lamp is glowing in ‘Low’ beam,
on pressing the switch, the head lamp ‘High’ beam
also glows along with the ‘Low’ beam.
Press the switch to flash the head lamp. It is used to
give signal to vehicles coming from the opposite
direction while overtaking other vehicles during day.
HANDLE BAR LEFT SIDE
1. Info switch
Info switch ‘ ‘ is used to cancel certain functions
and to start anad stop the ‘LAP’ etc. Press the
switch for particular action.
Press the switch ( ) to blow horn. It is used to
attract the attention of other road users in case of
danger.
2. Horn switch
3. Turn signal lamp switch
When the turn signal switch is moved to left ’ ‘
or right ‘ ‘, the corresponding turn signal lamps
flashes. To stop flashing, push the switch in.
KNOW YOUR TVS APACHE RTR 200 4V
Failure to switch the turn signal lamp ON or OFF at the
right time may lead to an accident.
Warning
4
5 6
3 2
1
Pass by system will not work if the head lamp is
glowing in High beam
Note
43
