WSS cable clamps - (front) I I I I I I – Fix new clamp, if missing
WSS / toner ring I & C I & C I & C I & C I & C I & C – Replace if damage
Service 1st 2nd 3rd 4th 5th Remarks
Every Every
km 500-750 2500-3000 5000-6000 8500-9000 11500-12000
3000 km 6000 km
Brake effectiveness I I I I I I –
Brake pedal shaft L L L L L L – Lubricate using TRU4 oil
Period from the date of sale 1 month 3 months 6 months 9 months 12 months
Brake fluid I & T I & T I & T I & T I & T I & T – Replace every 21000 km
Item Service
Brake pad wear I I I I I I – Replace if necessary
WSS cable I I I I I I – Replace if damage
Bundy tube mounting (all joints) I & TI I & TI I & TI I & TI I & TI I & TI – Inspect for leak
HECU mounting cushions – – I – I – I Replace every 30000 km
Master cylinder cups – – – – – – – Replace every 21000 km
Wheel freeness I I I I I I –
Engine idling RPM I & S I & S I & S I & S I & S I & S –
Brake hose / bundy tubes I I I I I I – Replace every 30000 km
Evaporative emission control I I I I I I – Check for intactness of
system hoses and canister
Ball joint gear shift lever – – L – L – L Lubricate using grease
Tyre pressure at cold condition I & S I & S I & S I & S I & S I & S –
Toner rings teeth damage I I I I I I – Replace if necessary
7
Idling CO% I & S – – – – – – I & S every 12000 km
63
MAINTENANCE
7
Idling CO% should be set with the help of exhaust gas analyser and tachometer only.
Contd...
