Tyco Electronics Galaxy SC Controller J85501F-1
Issue 13 February 2001 Configuration 4 - 27
TIME..: The sub menu to configure time.
The TIME menu is on the PLANT menu. From the PLANT menu
move the cursor to the TIME.. field and press <ENTER> key to bring
up the TIME menu:
Time Format (FORMAT): This field let the users configure the time
format as 12HR or 24HR. Use the <+> or <-> key to select the right time
format for the site and press <ENTER> to save the value.
Change the hour (HOUR): Use this field to change the hour; the possible
value is from 0 to 24.
Change the minute (MINUTE): Use this field to change the minute;
possible value is from 0 to 59.
Alarm Thresholds
Menu
Note: Most of the alarm threshold configurations have been described
previously under the Basic Controller. They are repeated here for
convenience.
From the CONFIGURATION menu select THRESH to bring up the
ALARM THRESHOLDS menu. This menu screen lets you configure
the alarm threshold for the High Voltage alarm (HV), High Float
Voltage alarm (HFV), Battery Discharged alarm (BD), and Very Low
Voltage alarm (VLV) for both FLOAT and BOOST mode. There is one
read-only field in this menu, the High Voltage Backup, the value of
which is determined by a hardware switch setting. The THRESH menu
should look like this:
CONFIG TIME
FORMAT : 12HR
HOUR : 5
MINUTE : 10
ALARM THRESHOLD CONF
FLOAT BOOST BACKUP
HV : 53.60 53.60 53.60
HFV : 53.00 53.00
BD : 51.00 51.00
VLV : 46.00
