Tyco Electronics Galaxy SC Controller J85501F-1
4 - 26 Configuration Issue 13 February 2001
shunt this results in 40 amps/mV. Then multiply this value by the
measured mV drop of the load type shunt.
RST PLI: The next field is the RST PLI which allows you to reset the
display to factory calibration for plant current (using the ADJ PLI field).
With the cursor is on this field, pressing the <ENTER> key will zero out
the delta for the plant current. The plant current value displayed now is
the true reading value as computed by Galaxy SC from the shunt
reading.
System Date Menu DATE..: The sub menu to configure date.
The DATE menu is on the PLANT menu. From the PLANT menu
move the cursor to the DATE.. field, press <ENTER> key to bring up
the DATE menu:
Date Format (FORMAT): This field allows you to select one of the
following date formats: MM/DD/YY, DD/MM/YY, YY/MM/DD, MM/
DD/YYYY, DD/MM/YYYY, YYYY/MM/DD. Use the <+> or <-> key
to select the desired format and press <ENTER> to save the change.
Change the month (MONTH): Use this field to change the month; the
possible value is from 1 to 12.
Change the day (DAY): Use this field to change the day of the month;
the possible value is from 1 to 31.
Change the year (YEAR): Use this field to change the year; the
possible value is from 1992 and up to 2067.
Please note that the system will validate the entries before the system
date is modified.
System Time Menu To set the time in EasyView follow the menu path: Configure → System
→ System Time.
CONFIG DATE
FORMAT : MM/DD/YYYY
MONTH : 01
DAY : 08
YEAR : 1995
