Tyco Galaxy SC Controller User Manual

Tyco Electronics Galaxy SC Controller J85501F-1
Issue 13 February 2001 Configuration 4 - 29
Alarm Menu From the CONFIGURATION menu select ALARM to bring up the
ALARM menu. This menu will allow you to enable or disable various
alarm operations. (The majority of these configurations are the same as
for the basic controller. They have been repeated here for the
convenience of the user.)
Set Critical alarm equal Major alarm (CR=MJ): A hardware DIP
switch (switch 6 of SW202 on the BJB board) and a software switch are
associated with this field. If this field is enabled, all the CRITICAL
alarms in the system will behave as if they are at the MAJOR severity
level. If you want to enable this field, make sure the hardware DIP
switch is ON, and use the <+> or <-> key to set the field value as
ENABLE; press <ENTER> key to save the change. This option is useful
for customer alarm systems which recognize only MAJOR and MINOR
alarm levels and not the new third level, CRITICAL.
Test Alarm (Test ALM) enable/disable switch: A hardware DIP
switch (switch 5 of SW202 on the BJB1 board) and a software switch
are associated with this field. You must enable this field to perform an
alarm test. Make sure the hardware DIP switch is ON and use the <+>
or <-> key to set the field value as ENABLE; press <ENTER> key to
save the change.
Test High Voltage (TEST HV) enable/disable switch: A hardware
DIP switch (switch 4 of SW202 on the BJB1 board) and a software
switch are associated with this field. This field must be enabled in order
to test the High Voltage shutdown of rectifiers during alarm test. To
enable this field, make sure the hardware DIP switch is ON and use the
<+> or <-> key to set the field value as ENABLE; press <ENTER> key
to save the change. Enabling of this switch is not recommended with
serial rectifiers.
Alarm Cut Off for Critical alarm (ACO CR) enable/disable switch:
This field controls the Alarm Cut Off operation for the Critical severity
level alarms. This field must be enabled for the ACO button field on the
MAIN menu to have effect. To enable this field, use the <+> or <-> key
ALARM
TEST ALM : EN
TEST HV : DIS (S)
RMT TEST : DIS (S)
ACO CR : EN
ACO MJ : EN
ACO MN : EN CR = MJ : EN
