to set the field value as ENABLE; press <ENTER> key to save the
change.
Alarm Cut Off for Major alarm (ACO MJ) enable/disable switch:
This field controls the Alarm Cut Off operation for the Major severity
level alarms. This field must be enabled for the ACO button field on the
MAIN menu to have effect. To enable this field, use the <+> or <-> key
to set the field value as ENABLE; press <ENTER> key to save the
change.
Alarm Cut Off for Minor alarm (ACO MN) enable/disable switch:
This field controls the Alarm Cut Off operation for the Minor severity
level alarms. This field must be enabled for the ACO button field on the
MAIN menu to have effect. To enable this field, use the <+> or <-> key
to set the field value as ENABLE; press <ENTER> key to save the
change.
Remote Alarm test (REM TEST) enable/disable switch: This field
lets you enable or disable the remote test feature. The switch must be
enabled for the feature to work. This field has a hardware DIP switch
(SW204-2) and a software switch. To enable the field, turn on the DIP
switch and use the <+> or <-> key to set the value; press <ENTER> key
to save the change.
Rectifier Manager
Menu
This menu selection is a sub menu for Rectifier Definition, Rectifier
Control, and Rectifier Operation. To view it, move the cursor to the
CONFIG menu selection, RECT MNGR and press <ENTER> to view
the RECTIFIER MANAGEMENT menu.
Rectifier Definition
Menu
Parallel rectifiers, using L-31 to L-35 RIMs and L-21 (BJC1) or L-22
(BJC2) RIBs, must be configured for use with the Intelligent controller.
Serial rectifiers, using L-36 RIM and L-23 (BJC3) RIB, are
automatically recognized and configured in the system. Use this REC T
MNGR menu to review the configuration for serial rectifiers or to
complete the configuration for parallel interface. First move the cursor
RECTIFIER MANAGEMENT
RECT DEF: 01
RECT CNTRL..
RECT OPER..:
To Next Page
