Tyco Electronics Galaxy SC Controller J85501F-1
Issue 13 February 2001 Configuration 4 - 31
to the RECT DEF item and press <+> or <-> key to choose rectifier
number.
For serialized plants, no changes will be necessary. For parallel interface
plants, use the <+> or <-> key in the TYPE field to choose the rectifier
type connected to the respective rectifier port. Note that for rectifier
types not listed, “G” can be used to represent “Generic.” Thus “G200”
would represent a non-Tyco/AT&T 200A rectifier type.
The SHNT mV and MAN SW fields are used only when a “Generic”
style rectifier has been selected. Use the <+> or <-> key in the SHNT
mV field to configure the rectifier shunt mV reading which corresponds
to the rated capacity of the associated rectifier. Thus a 400A rectifier
with a 500A/50mV shunt would be configured as a “G400” with 40mV
representing the rated 400A capacity of the rectifier.
MAN SW field selections are NONE, OPEN and CLOSED. Use the
<+> or <-> key to configure the proper interpretation of the MAN signal
from the associated rectifier. MAN is the signal generated when the
rectifier is turned off manually with its power switch.
Rectifiers Control
Parameters Menu
From the RECT MNGR menu, move the cursor to the RECT CTR
field; press <ENTER> to bring up the RECTIFIER CONTROL menu.
This menu lets you configure all the rectifiers connected to the Galaxy
SC. The following shows the menu:
Enable/Disable Automatic Rectifier Restart (AUTO RST): This
field allows automatic restart of rectifiers after an RFA condition. This
field has a hardware switch (switch 7 of SW202 on the BJB board) and
RECTIFIER 01
TYPE : 570A
SHNT mV : 50.00
MAN SW : NONE
RECTIFIER CONTROL
AUTO RST : EN
REMOTE ON : EN
REMOTE OFF : DIS(S)
SEQUENCE : DIS(S)
ON THRESH : 44.00
EFFICIENCY : EN
