Tyco Electronics Galaxy SC Controller J85501F-1
4 - 34 Configuration Issue 13 February 2001
Note: this value is based on rectifier output voltage and not measured
plant voltage. Move the cursor to one of the fields and use the <+> or
<-> key to adjust the voltage to the desired level. Press <ENTER> to
save the change.
VOLT STEP: The configuration of this field sets the increment of
voltage change for the voltage settings above, in increments of 0.01, 0.1
or 1.0 volts. Use the <+> or <-> key to select the desired step change
voltage increment level. Press <ENTER> to save the change.
LD SHARE: The configuration of this field enables or disables the
rectifier load share feature. Use the <+> or <-> key to toggle between
enable or disable. Press <ENTER> to save the change.
RMOVE RECT: May be used to remove a rectifier from the
configuration. Rectifier number is selected using <+> and <-> keys,
enter will remove the specified rectifier from the configuration. This
will only work if the rectifier is first physically removed from the
system.
Boost Menu From the CONFIG menu, move the cursor to the BOOST field and
press <ENTER> to bring up the BOOST menu:
Configure Boost (BOOST) enable/disable switch: This field must be
enabled before the plant can be switched from the FLOAT mode to
BOOST mode; the MODE field in the MAIN menu does the actual
switching. This field has a hardware DIP switch (SW202-3 on BJB
board) and a software switch. To enable the field, use the <+> or <-> key
to change the field value and press <ENTER> to save it.
Configure the External Boost (EXT) enable/disable switch: This
field controls the external boost, which can be initiated via wiring to BJT
TB3 23-39. This field has a hardware DIP switch (SW202-3 on BJB
board) and a software switch. To enable the field, use the <+> or <-> key
to change the field value and press <ENTER> to save the change.
BOOST
BOOST : EN
EXT : EN
BTP : DIS
AUTO : OFF
