18.Connect four work port tubes to SCV.
Tighten tube nuts to 40-57N.m(30-43 lb-ft).
19.Connect battery negative terminal.
20. Install fenders.
21.Install seat and seat platform
22.Install LH and RH closeout panels.
23.Install operator’s platform.
24. Install floor mat.
25.Refill hydraulic oil reservoir to proper
level.
26.Bleed air from hydraulic system
(See HYDRAULIC SYSTEM BLEED
PROCEDURE)
2.HYDRAULIC TRANSMISSION
REMOVAL & INSTALLATION
Removal:
1.Park tractor on level surface.Stop engine
and release hydraulic pressure by operating
all controls.
NOTE: Drive shaft may come out with
transmission.If removed with
transmission,remove from
transmission,and install into tunnel and
range transmission.
Installation:
Installation is the reverse of removal.
- Clean flanges of transmission and tunnel
before applying sealant.
- Apply TB1215 sealant to flanges of
transmission where it contacts the tunnel.
- Tighten the screws attaching transmission to
tunnel to 126-154 N.m(95-115lb-ft).
IMPORTANT:
If neutral adjustment locking screws was
loosened,neutral adjustment procedure must be
performed. See “HYDROSTATIC PEDAL
AND NEUTRAL ADJUSTMENT”
CAUTION
To avoid injury from escaping
hydraulic oil under pressure ,relief the
pressure in the system by stopping the
engine and operating all hydraulic
2.Separate tractor engine and tunnel sections.
(See TRACTOR SPLITTING(FRONT).
3.Remove two cap screws,two spacers,and
two lock nuts,and disconnect transmission
forward and reverse control rods.
NOTE: 1 screw is removed from the top of
the tunnel section ,from the outside.
4. Remove five screws attaching transmission
to tunnel section.Note length and location
of screws when removing.
NOTE:Oil may drain from the pump and
motor unit after it is removed.Have a
suitable container ready to catch excess
oil.
5.Gently pry around edges of flanges to break
sealant.Remove transmission.
4-23
