25
-
4. Inputting the presser type
(1) Setting procedure of the presser type
1) Call the presser type setting parameter
Press “Mode” key
❹
and memory switch
(level 1) edit screen A is displayed.
2) Select the presser type
Press Data Change key
❼
, and the picture
is changed as shown in the illustration below. Se
the presser type B mounted on the sewing
machine referring to (2) Table of presser type
below.
(2) Table of presser type
Engraved part number of presser should be in line with the type of presser.
Type 1
Type 2
Type 3
Type 5*
* Set type 5 when using the presser other
than type 1 to 3.
Change Presser size width
and Presser size length of the
memory switch (level 1) to adjust the
presser to be used. Refer to “V-21.
Method of changing memory switch
data” (P.51).
* When using type 5 with stitch width of
6mm or more and 41mm or more in
length, it is necessary to replace
components such as presser arm, feed
plate, etc.
To Next Page
