typical GT1790A - Setting Sewing Data (With;Without Edit)

-
38
-
12. Method of setting sewing data with/without edit
This sewing machine has been set so as not to be capable of editing sewing data items which are less
frequently used at the time of your purchase. When you desire to set the data more closely in
accordance with the sewing products, set the sewing data item to the edit possible state and use the
machine.
* For the setting of “with/without edit” for the sewing data, when S052 right parallel section
tension is set to “without edit”, sewing is performed with the data of S051 left parallel section
tension. When S056 2
nd
bar-tacking tension is set to “without edit”, sewing is performed with
the data of S055 1
st
bar-tacking section.
When the sewing data items other than the above ones are set to “without edit”, the data to be
referred are the initial value data.
1) Set the mode to the input mode
Under the input mode where Set Ready LED
goes out, data setting is enabled. In sewing mode,
press ❷ to change over the mode to input
mode.
2) Call sewing data with/without edit changeover
screen
Press Mode key ❹ . Select “05 Select to
edit sewing data”. The data edit enable/disable
changeover screen A or B are displayed.
3) Select sewing data to be changed over
Press Item Selection key❻ , and select data
item C to be changed over. At this moment, only
items which could be changed over could be
selected.
4) Changeover of with/without edit
When Data Change key ❼ is pressed, the
icon display C for the currently-selected sewing
data is changed over.
ON: With edit
OFF: Without edit
Return to step 3), and plural sewing data items can
be changed over.
5) Save set data
When Return key ❾ is pressed, the
changed-over state is saved and the screen returns
to the mode screen. When Reset key ❸ is
pressed, the screen returns to the previous screen.
(With edit)
(Without edit)
