UE Systems ULTRAPROBE 10000 User Manual

Version 1
30
• Sensitivity Mode = Manual
• Headphone Volume = 99%
• Turn off Time = 5 Seconds
• Shut off Mode = Timed
The user defined Default Settings can be:
• User Sensitivity Default (see Setup Menu 13)
• User Frequency (see Setup Menu 14)
• Frequency Adjust (see Setup Menu 15)
To select Default Settings:
1. Follow the steps to Enter the Setup Mode as described earlier
2. Spin to Menu12: Default Settings
3. Click to Enter
4. Spin to “YES” or “NO”
5. Click to set
6. Press the Yellow ENTER button to exit
Menu 12 Select
Default
Default
Default Settings
Settings
Settings
Press ENTER to
Confirm =
Confirm =
Exit
(NO)
(YES)
Menu 13: Sensitivity Default
The user can select a default sensitivity level ranging from 0-70
1. Follow the steps to Enter the Setup Mode as described earlier.
2. Spin to Menu 13: Sensitivity Default
3. Click to Enter
4. Spin to selected sensitivity level
5. Click to set
6. Press the Yellow ENTER button to exit.
Menu 14: User Frequency Default
This is the frequency to which the instrument will automatically default when turned on.
1. Follow the steps to Enter the Setup Mode as described earlier
2. Spin to Menu 14: Frequency Default
3. Click to Enter
4. Spin to desired frequency
5. Click to set
6. Press the Yellow ENTER button to exit
Menu 15: Frequency Adjust
Select YES to manually change frequency during operations. Select NO to fix a selected (default) fre-
quency to be used during all inspections.
1. Follow the steps to Enter the Setup Mode as described earlier
2. Spin to Menu 15: Frequency Adjust
3. Click to Enter
4. Spin to YES or NO
5. Click to set
6. Press the Yellow ENTER button to exit
