Version 1
37
Menu 32: dB offset value
This position is selected to set the dB scale for readings to be taken in dB offset scale.
To set the dB offset scale:
1. Follow the steps to Enter the Setup Mode as described earlier
2. Spin to dB Offset Val (value) (Menu 32 blinks) and click in the Sensitivity Control Dial
3. The dB Val (00) will blink
4. Spin the Sensitivity Control Dial to the desired dB value level
5. Click the Sensitivity Control Dial to set
6. Press the Yellow ENTER button to exit
Menu 33: Auto Store to CF
On Power Off the instrument will automatically download all records from the instrument to the Compact
Flash Card. YES will set the Auto Store feature. If NO is selected, if the power should fail (e.g. battery
discharges) data will not be saved to the Compact Flash Card.
To select this feature:
1. Follow the steps to Enter the Setup Mode as described earlier
2. Spin to Auto Store to CF (Menu 33 blinks)
3. Click in the Sensitivity Control Dial.
4. Spin the Sensitivity Control Dial to YES or NO
5. Click the Sensitivity Control Dial to set
Menu 34 Upgrade UP 10K PGM
This will be used for all future upgrades. This option enables users to upgrade firmware on-board the
instrument using the Compact Flash Card.
Please Note:
1. Do not update without new software loaded into the flash card!!!!!!!
2. Be sure the instrument is fully charged before any Compact flash Card upgrade procedures.
3. Do NOT remove the Compact Flash Card during the upgrade process.
To Upgrade:
1. Turn off Ultraprobe
2. Insert Compact Flash Card
3. Turn on Ultraprobe
4. Enter Setup mode
5. Spin to 34 Upgrade UE 10K
6. Click the Sensitivity Control Dial
After the upgrade process the instrument will shut down and revert to all Factory Default Settings (see
Menu 12: Default Settings)
