Version 1
33
When ready to enter temperature:
1. Click the Sensitivity Dial until the cursor moves do the bottom of the Display Panel
2. Until Press Enter for is blinking
3. Spin until the specific Application Info is blinking (e.g.: Generic or Steam)
4. Press Enter to enter the Application Info screen
5. Spin to Temperature
6. Turn on the Thermometer and take the temperature measurement and hold the reading
7. Click (the temperature numerals will blink rapidly) and the data will be entered
8. (Optional) Click to re-enter the data
9. Press Enter to save: the temperature will be stored
10. NOTE: If you wish to move the data to an-other location the store screen will prompt you to spin to
the desired location and then to press Enter again
11. You will be given a prompt to press Enter to Exit
12. Click to exit
You need to use the proper cable connection for this input. The Line Input Jack Specifications are: 1/8”
phone jack, tip positive, sleeve negative. Input level is 0-5 V DC maximum. Input resistance is 50 k
OHMS. Transfer function: 1 mV DC/degree (ºC or ºF). Input range: 10º to 475º (ºC or ºF)
Menu 23: Sensitivity Mode MANUAL / AUTOMATIC (Auto Sens. 0 to 70 up or
down)
The instrument’s sensitivity can be adjusted manually or automatically. In the manual mode, if a sensed
ultrasound is too loud or too soft, or out of range, the inspector must adjust the sensitivity up or down
using the Sensitivity Control Dial. In automatic, the inspector can pre-select a sensitivity level that will
represent a percentage of the scale displayed on the bar graph. The levels are 0 to 99 (%). For loud
environments, the range will be down scaled, while for inspections where high sensitivity is required; the
level can be scaled up. For recording sounds, as an example, the automatic scale should be set at 50 or
lower. At 50 the instrument will attempt to maintain a 50% of scale reading on the bar graph. If the sound
level is too low, the bar graph level will drop below 50%. If the level is high, the instrument will attempt to
maintain an average of 50% on the bar graph. The volume level will also rise and fall in relation to the set
sensitivity level.
To select an automatic response:
1. Follow the steps to Enter the Setup Mode as described earlier
2. Spin to Menu 23 Sensitivity Mode
3. Click to Enter
4. Spin from Manual to Automatic
5. Spin to the percent of scale desired
6. Click to exit
7. Press the Yellow ENTER button to exit.
