Version 1
31
Menu 16: Restore Lists
Selecting Restore Lists resets inspection codes to original factory set codes listed in Ultratrend DMS and
in the Ultraprobe 10,000.
This change will effect only the current information stored locally on the Ultraprobe and can be changed
again when downloaded to
Ultratrend DMS. YES will restore the lists to the original factory lists, NO will retain current codes.
1. Follow the steps to Enter the Setup Mode as described earlier.
2. Spin to Menu 16: Restore Lists
3. Click to Enter
4. Spin to YES or NO
5. Click to set
6. Press the Yellow ENTER button to exit.
Menu 17: Set Shutoff Mode Shutdown = Timed Trigger
There are two selections to control how to turn the instrument off: Either by a Timed turn-off (as in-Menu
16) or when the trigger is released: Trigger. In Trigger Mode, when the trigger is pressed to turn the
Ultraprobe on, the instrument will stay on until the trigger is pulled a second time.
To set the Shutoff Mode:
1. Follow steps to Enter the Setup Mode as de-scribed above
2. Spin to Menu 17: Set Shut off Mode
3. Click to Enter
4. Spin to “Timed” or “Trigger”
5. Click to set
6. Press the Yellow ENTER button to exit
Menu 18: Set Turnoff Time Turn off = 0-3 minutes preset at 5 seconds
1. Follow the steps to Enter the Setup Mode as described earlier
2. Spin to Menu 18: Set Turn off Time
3. Click to Enter
4. Spin to the desired time (0 seconds to 300 seconds (5 minutes) The Factory default is 5 seconds.)
5. Click to set
6. Press the Yellow ENTER button to exit
Menu 19: Set WAV Sample Rate
The instrument recording sample rate is normally 16000 Hz. It can be changed to a slower rate of 11025
Hz.
1. Follow the steps to Enter the Setup Mode as described earlier
2. Spin to Menu 19: Set WAV Sample Rate
3. Click to Enter
4. Spin to desired rate
