ļ§ Hydraulic diagram
E.g. Stella 3GR diagram
1 ID-75 TUBE FLEXIBLE COUDE ARNE INOX FLEXIBLE PIPE
2 NZ6015 TUBE EVACUATION SOUPAPE HP HP VALVE DRAIN TUBE
NZ6016 TUBE EVACUATION SOUPAPE HP (V+) HP VALVE DRAIN TUBE (V+)
3 NZ6011 TUBE REMPLISSAGE CHAUDIERE BOILER FEEDING PIPE
4 NZ6008 RAMPE DOSEUR ET ENTREE EAU WATER FEEDING & DOSER PIPE
5 NZ6007 RAMPE DOSEUR EAU WATER DOSER PIPE
6 NZ6012 TUBE CAPTEUR RESEAU NETWORK SENSOR PIPE
7 NZ6006 TUBE ALIMENTATION GROUPE GROUP FEED PIPE
7 NZ6018 TUBE ALIM. GROUP PRE INFUSION PRE-INFUSION GROUP FEED PIPE
8 NZ6013 TUBE CAPTEUR VAPEUR STEAM SENSOR PIPE
9 NZ6010 TUBE ROBINET VAPEUR STEAM TAP PIPE
10 25902 SORTIE VAPEUR STELLA INOX STELLA S/S STEAM OUTLET
10 25903 SORTIE VAPEUR STELLA V+ INOX STELLA V+ S/S STEAM OUTLET
11 NZ6004 TUBE EV VAPEUR STEAM SOLENOID VALVE PIPE
12 25902 SORTIE VAPEUR STELLA INOX STELLA S/S STEAM OUTLET
12 25903 SORTIE VAPEUR STELLA V+ INOX STELLA V+ S/S STEAM OUTLET
12 NZ1020 SORTIE STEAMAIR STELLA STELLA STEAMAIR OUTLET
12 NZ1021 SORTIE STEAMAIR STELLA V+ STELLA V+ STEAMAIR OUTLET
13 NZ6005 TUBE EV EAU CHAUDE HOT WATER SOLENOID VALVE PIPE
14 DV1024 SORTIE EAU CHAUDE REGLABLE ADJUSTABLE HOT WATER OUTLET
15 NZ6000 TUBE DECOMPRESSION DECOMPRESSION PIPE
15 NZ6001 TUBE DECOMPRESSION V+ V+ DECOMPRESSION PIPE
