4. FEATURES OF THE STELLA DI CAFFE
The machine is delivered in a cardboard packing case and screwed to a wooden pallet.
Unpacking the machine
Cut the bands
Open the box and take out the box holding the accessories
Separate the cardboard packing case from the pallet
Unscrew the nuts holding the machine to the pallet while tilting the control box slightly
Remove the machine from the pallet and place it on wooden blocks
Remove the screws and washers used for the transport
Preparation of the location and installation of the machine
Position the machine in its final location and level it with rubber washers if necessary
It is essential to leave a free space of 5 cm behind the machine if it is against a wall
Take care never to obstruct the air intakes on the top of the machine
The machine requires an earthed electricity wall socket corresponding to the specifications on the machine,
a water supply and a "waste water" drain with trap.
5. COMMISSIONING
Water connection
Fit a filter upstream of the machine - Check the hardness of the water: 5° to 10° KH recommended – If
necessary use a water softener
.
Water supply
- Pressure: 0 - 10 bars
- Connection: 3/8" female gas thread (male connection on the machine) - Supplied with the machine
- Pipe: minimum inside diameter 8 mm
- Install a stop tap on the supply
To connect the water it is necessary to remove the right side panel from the machine:
Unscrew the fixing screws next to the cup warmer and pull the side panel towards the back
Screw the elbow end (3/8') of the braided flexible pipe to the brass connection on the right of the machine,
and the straight end (1/2') to the water mains connection or the water softener outlet (if used)
If a water softener is used, wash it out before using it.
Check for leaks
Refit the side panel on the machine
