SPECIFICATIONS
MAST - 1H2 (SRX35N)
Mast Name
Maximum Fork Height
in (mm)
Free Lift
without
Backrest
in (mm)
Tilt Angle
Forward/Backward
Overall Height
Lowered Mast Position
in (mm)
Extended Mast Position
in (mm)
Top of OHG Mast (OHL) With Backrest Without Backrest
THREE STAGE
(Full Free)
3F198 198 (5030) 54.1 (1375)
3/4
87.5 (2225) 89 (2260) 247.8 (6295) 234.7 (5960)
3F210 210 (5335) 60.1 (1530)
93.5 (2375)
95 (2415) 260.3 (6615) 247.2 (6280)
3F240 240 (6095) 72.1 (1830) 107 (2720) 290.4 (7380) 277.3 (7045)
3F270 270 (6860) 84.1 (2140) 119 (3025) 320.5 (8140) 307.4 (7810)
