GENERAL CARE AND MAINTENANCE
HOW TO CHARGE BATTERY (OFF-FORKLIFT TYPE)
(cont’d)
5. When charging has been completed, the charging circuit
automatically opens. At this point, the Initial (1st) lamp, 2nd lamp,
Final lamp and OK (charge completion) lamp will all come on to
indicate that charging has been completed.
At this time, the charging mode lamp will go out.
6. After ensuring that the Initial (1st and 2nd), Final and OK lamps are
on, disconnect the charger output connector from the battery plug.
All lamps will then go out.
NOTE:
• Do not disconnect the input plug while charging is taking place.
• Before disconnecting the charger output plug from the battery plug,
make sure the Initial (1st and 2nd), Final and OK lamps are lit (4
lamps in all).
WARNING
!
!
• If the CHECK lamp remains on after charging the battery, the
problem may be due to a malfunctioning main timer or an
abnormal battery. Immediately contact your Local Authorized
Dealer for inspection. When the charger output plug is
disconnected from the battery plug, the CHECK lamp will go
out.
• Leave the battery lid open during the charging process.
WARNING
!
!
• While the battery is being charged or immediately afterward,
inammable gases are actively produced. Be careful to keep
any open ame away from the battery.
• Before charging the battery, add distilled water up to the
upper limit level. Do not overll.
• If a fuse located on the transformer is blown, replace it with
one of the same type and rating.
• Periodically clean the caps, removing any foreign matter
from gas vents. The caps need not be removed during the
charging operation.
• When charging is complete, ascertain with a gravimeter that
the specic gravity is 1.28 at a temperature 20°C (68°F).c
